Product Description
Overview
The Syntel NEOS Nexgen Lite is a next-generation hybrid IP PBX engineered to deliver high performance, flexibility, and reliability for small and medium businesses. It seamlessly integrates Analog, SIP, PRI, and GSM connectivity in a single cabinet, making it a future-ready communication solution without added complexity.
Powered by a 1 GHz processor and a stable Linux operating system, Nexgen Lite ensures smooth call handling, secure operation, and consistent performance. Designed and manufactured in India by Syntel by Arvind, it offers excellent value with easy installation and low maintenance.
Why Choose NEOS Nexgen Lite
- Hybrid IP PBX with Analog, SIP, PRI, and GSM support
- Single cabinet design for quick installation
- No complex licensing structure
- Web-based configuration and live status monitoring
- Ideal for growing offices and SME environments
Capacity & Architecture
- Supports up to 64 IP extensions or IP KTS
- Single cabinet supporting up to 64 TDM ports
- Concurrent TDM-IP calls: up to 20 channels
- Supports third-party SIP phones
- Up to 8 SIP-PRI accounts with two service providers simultaneously
Auto Attendant & Conferencing
- Multi-level 8-port auto attendant
- User-recordable voice prompts
- Meet-me conferencing
- Adhoc conference calling
- 3-party conference support
Call Control Features
- Call hold, call park, call pickup (selective and group)
- Call transfer, call split and call waiting
- Auto callback on busy and no reply (extension and junction)
- CLI-based routing
- Executive ring and distinctive ring for SLT
- Last number and last junction number redial
- Least Cost Routing (LCR)
- Hunt groups and abbreviated dialing
Advanced System Features
- GUI-based system configuration and management
- Remote programming through PC connectivity
- Web interface for live system status
- System log for maintenance and diagnostics
- Internal voice prompts
- Flexible numbering plan
- Day and night mode with manual or automatic switching
- Call billing support
- Class of Service (COS) control
Voice Mail & Messaging
- 4-channel voice mail system
- Up to 4 hours voice mail storage
- Remote access to voice mailboxes
- Message waiting indication support
Connectivity & Interfaces
- Ethernet connectivity for IP communication
- RS232 PC connectivity
- Proprietary TIE connectivity with Nexgen systems
Physical & Technical Specifications
- Dimensions: 360 × 160 × 464 mm (W × H × D)
- Weight: 6 kg (without cards)
- Operating voltage: 210–240 VAC, 50 Hz
- Battery backup support: 24V, 7Ah × 2 batteries
- Operating temperature: 0°C to 50°C
Certifications & Origin
- ISO certified
- Made in India
- Designed and manufactured by Syntel by Arvind
Ideal For
- Small and medium offices
- Retail chains and branch offices
- Hospitals, clinics, and institutions
- Hotels and hospitality projects
- Organizations upgrading from analog to IP-ready systems
Specifications are based on the official Syntel by Arvind NEOS Nexgen Lite brochure.
